Exquisite Structure Manufacturing Tree Growth Cones

Tree growth cone uses

Forestry research often requires sampling and measurement of trees, and tree growth cones are a fast and reliable tool for calculating the age of trees. Without damaging the normal growth of trees, it analyzes and determines tree growth rate, tree age, tree growth firmness, tree growth environment pollution, and nutrient migration, and other related conditions by drilling wood core samples. The Haglof growth cone uses Swedish carbon steel to ensure the robustness and durability of the growth cone and rapid sampling. Applied to forestry, forest ecology, and other fields. It can also be used to measure the degree of deep keratinization of trees, detect wood and wooden buildings, and identify the age of ancient trees.

Tree growth cone length selection

For different woods and trees, tree growth cones with different lengths and different sampling diameters can be selected. If the diameter of the tree is 1 meter, just choose a growth cone with a length of 50 cm. The more commonly used growth cone is about 30cm. If the material of the tree is hard, it is recommended to choose a 2-thread thread and the sampling core diameter is 5.15mm. If the tree is thick, it is necessary to choose a growth cone with a length of 80cm or more. It is recommended to select a tree growth cone with a sampling core diameter of 12mm.

Tree growth cone characteristics

The tree growth cones are made of high-quality Swedish special steel, which ensures that the Swedish growth cones are durable and quick to sample. The drill has two-thread and three-thread thread options, suitable for different woods. The boring drill bit is coated with Teflon to reduce the resistance of the drill bit in and out, and the handle is equipped with a PTFE anti-skid sleeve.

Types of tree growth cones:

Tree growth cones are divided into four types according to the sampling diameter:

Different sampling diameters: 4.35, 5.15, 10, 12 mm. Except for special purposes, a growth cone with a diameter of 5.15mm is generally selected. In order to reduce damage to trees, it is recommended to use tree growth cones with a diameter of 4.3mm.
Tree growth cones are divided into two types according to the thread of the drill bit:

Two-thread and three-thread threads. The two-thread threaded growth cone is suitable for hard trees and can be rotated into 8mm per rotation.
The three-thread thread type is suitable for softer trees and can be rotated into 12mm per rotation. If possible, try to choose a two-thread screw type, this kind of growth cone has a longer life.
Tree growth cones are divided into 13 specifications of 10-100 cm in length

The specific specifications, models, and dimensions of tree growth cones are as follows:

Product specification model

4.35mm/5.15mm diameter (two-thread/three-thread thread):

CO100 growth cone, length 100mm, Increment Borer 100 mm

CO150 growth cone, length 150mm, Increment Borer 150 mm

CO200 growth cone, length 200mm, Increment Borer 200 mm

CO250 growth cone, length 250mm, Increment Borer 250 mm

CO300 growth cone, length 300mm, Increment Borer 300 mm

CO350 growth cone, length 350mm, Increment Borer 350 mm

CO400 growth cone, length 400mm, Increment Borer 400 mm

CO450 growth cone, length 450mm, Increment Borer 450 mm

CO500 growth cone, length 500mm, Increment Borer 500 mm

5.15mm diameter (thread two-wire/three-wire)

CO600 growth cone, length 600mm, Increment Borer 600 mm

CO700 growth cone, length 700mm, Increment Borer 700 mm

CO800 growth cone, length 800mm, Increment Borer 800 mm

CO1000 growth cone, length 1000mm, Increment Borer 1000 mm

10mm diameter (second thread)

CO300A 300 mm long tree growth cone, 10 mm inner diameter, 2 wires.

CO400A 400 mm long tree growth cone, 10 mm inner diameter, 2 wires.

CO500A 500mm long tree growth cone, 10mm inner diameter, 2 wires.

CO1000A 1000 mm long tree growth cone, inner diameter 10 mm, 2 lines.

12mm diameter (second thread)

CO300B 300mm long tree growth cone, 12mm inner diameter, 2 wires.

CO450B 450mm long tree growth cone, 12mm inner diameter, 2 wires.

CO800B 800mm long tree growth cone, 12mm inner diameter, 2 wires.
