Good Selling Products Digital Magnetic Hotplate Stirrer

» General Lab Equipment » Good Selling Products Digital Magnetic Hotplate Stirrer

    • Good Selling Products Digital Magnetic Hotplate Stirrer

    CATEGORY AND TAGS:
    General Lab Equipment

    Model: MS-H-ProA

    enquiry
    • Specifications
    Key Features

    • Digital control with max. the temperature at 340℃，max speed up to 1500rpm.
    • Aluminum cover with ceramic coating work plate provides fast heating performance and strong compatibility with various heating
    containers and heating blocks.
    • High-resolution LCD display shows actual temperatures and speed.
    • PID controller ensures a precise and steady heating process.
    • External temperature control is possible by connecting the temperature sensor(PT 1000) with accuracy at ±0.2°C.
    • Brushless DC motor enables more powerful speed control.
    • Three heating modes for selected ( fast heating, standard heating, and stable heating ).
    • Remote control function through RS232 interface provides PC control and data transmission.

    Specifications
    Specifications
    MS-H-ProA
    Work plate dimension
    φ135mm(5inch)
    Work plate material
    Aluminum cover with ceramic coating
    Motor type
    Brushless DC motor
    Heating temperature range
    Room temp.-340℃, increment 1℃
    Temperature display accuracy
    ±0.1℃
    Heating power
    600w
    Speed range
    100-1500rpm resolution±1rpm
    Max. stirring quantity[H2O]
    20L
    Speed display
    LCD
    Temperature display
    LCD
    Motor rating input
    18w
    Motor rating output
    10w
    Max. magnetic bar[length]
    80mm
    Temperature control accuracy
    ±1°C(<100℃) ±1%(>100℃)
    External temperature sensor
    PT1000 (accuracy ±0.2℃)
    Over-temperature protection
    420℃
    “Hot” warning
    50℃
    Data connector
    RS232
    Protection class
    IP21
    Voltage
    100~120/200-240V 50/60Hz
    Power
    650w
    Dimension[WxDxH]
    280×160×85mm
    Weight
    2.8kg
